Crystal Unit (kHz)
It is a product lineup of Crystal Unit (kHz). Click on a model name to see its features and specs.
kHz Crystal Unit
| Model | Size | Nominal frequency | Frequency tolerance | Operating temperature | E.S.R | Load capacitance | Product features | |||
|---|---|---|---|---|---|---|---|---|---|---|
| (mm: L × W) | (mm: H Max.) | min. (kHz) | max. (kHz) | @ 25 ℃ (ppm) | min. (℃) | max. (℃) | (kΩ) | (pF) | ||
| TFX-05X Product catalog | 1.2 × 1.0 | 0.35 | 32.768 | 32.768 | ±20, ±30, ±50, other |
-40 | +105 | 90 Max. | 5.0, 7.0, 9.0, 12.5 (Please specify) |
“Crystal Package” created with “Metal Diffusion Sealing” |
| TFX-04C Product catalog | 1.6 × 1.0 | 0.5 | 32.768 | 32.768 | ±10, ±20, ±30, ±50, other |
-40 | +105 | 60 Max. | 5.0, 7.0, 9.0, 12.5 (Please specify) |
Low-ESR type : TFX-04 |
| TFX-04 Product catalog | 1.6 × 1.0 | 0.5 | 32.768 | 32.768 | ±10, ±20, ±30, ±50, other |
-40 | +105 | 90 Max. | 5.0, 7.0, 9.0, 12.5 (Please specify) |
|
| TFX-03C Product catalog | 2.0 × 1.2 | 0.6 | 32.768 | 32.768 | ±10, ±20, ±30, ±50, other |
-40 | +105 | 50 Max. | 5.0, 7.0, 9.0, 12.5 (Please specify) |
Low-ESR type : TFX-03 |
| TFX-03 Product catalog | 2.0 × 1.2 | 0.6 | 32.768 | 32.768 | ±10, ±20, ±30, ±50, other |
-40 | +105 | 90 Max. | 5.0, 7.0, 9.0, 12.5 (Please specify) |
|
| TFX-02S Product catalog | 3.2 × 1.5 | 0.8 | 32.768 | 32.768 | ±10, ±20, ±30, ±50, other |
-40 | +105 | 70 Max. | 7.0, 9.0, 12.5 (Please specify) |
|
